| DN Size | Inch Size | Ø (mm) | W (mm) | T (mm) | H (mm) | M (mm) | ØD (mm) | Surface Treatment |
|---|---|---|---|---|---|---|---|---|
| DN15 | 1/2” | 21 | 25 | 1.35 | 35 | 8×20 | 10 | Electroplated Finish |
| DN20 | 3/4” | 27 | 25 | 1.35 | 40 | 8×20 | 10 | Electroplated Finish |
| DN25 | 1” | 34 | 25 | 1.35 | 45 | 8×20 | 10 | Electroplated Finish |
| DN32 | 1 1/4” | 42 | 25 | 1.35 | 50 | 8×20 | 10 | Electroplated Finish |
| DN40 | 1 1/2” | 48 | 25 | 1.35 | 55 | 8×20 | 10 | Electroplated Finish |
| DN50 | 2” | 60 | 25 | 1.55 | 65 | 8×20 | 10 | Electroplated Finish |
| DN65 | 2 1/2” | 76 | 25 | 1.55 | 80 | 8×20 | 10 | Electroplated Finish |
| DN80 | 3” | 90 | 25 | 1.55 | 90 | 8×20 | 10 | Electroplated Finish |
| DN100 | 4” | 110 | 25 | 1.55 | 100 | 8×20 | 10 | Electroplated Finish |
| DN125 | 5” | 140 | 25 | 1.55 | 105 | 8×20 | 10 | Electroplated Finish |
| DN150 | 6” | 168 | 25 | 1.55 | 115 | 8×20 | 10 | Electroplated Finish |
| DN200 | 8” | 220 | 25 | 1.55 | 140 | 8×20 | 12 | Electroplated Finish |
