| Size | Inner Diameter (mm) | Outer Diameter (mm) | Width (mm) | Thickness (mm) | Height (mm) | Bolt | Bolt Hole |
|---|---|---|---|---|---|---|---|
| DN15 | 21 | 26 | 22 | 2.5 | 55 | M6 | M10 |
| DN20 | 27 | 32 | 22 | 2.5 | 60 | M6 | M10 |
| DN25 | 34 | 39 | 22 | 2.5 | 70 | M6 | M10 |
| DN32 | 42 | 47 | 22 | 2.5 | 86 | M6 | M10 |
| DN40 | 49 | 54 | 22 | 2.5 | 100 | M6 | M10 |
| DN50 | 60 | 66 | 22 | 3 | 115 | M6 | M10 |
| DN65 | 76 | 82 | 30 | 3 | 135 | M10 | M12 |
| DN80 | 90 | 96 | 30 | 3 | 155 | M10 | M12 |
| DN100 | 114 | 122 | 30 | 4 | 200 | M10 | M16 |
| DN125 | 140 | 150 | 40 | 5 | 250 | M12 | M16 |
| DN150 | 168 | 178 | 40 | 5 | 280 | M12 | M20 |
| DN200 | 220 | 230 | 50 | 5 | 330 | M16 | M20 |
