Key Features
• High Discharge Rate: K11.2 for rapid suppression in ordinary and light hazard occupancies
• Compact Design: Ideal for commercial and industrial systems
• Versatile Use: Suitable for upright or pendent installations depending on ceiling configuration
• Heat-Sensitive Bulb: Activates when reaching rated temperature
• Recessed Option: GS214 available with adjustable escutcheon for finished ceilings
Temperature Ratings
• 68°C (155°F)
• 93°C (200°F)
Technical Specs
• Thread Size: ¾" NPT
• Discharge Coefficient: K = 11.2 (161 L/min/bar½)
• Max Working Pressure: 175 psi (12 bar)
• Wrench Type: W-Type 34 Sprinkler Wrench
Material
• Frame / Deflector / Compression Screw / Plug: Brass
• Bulb: Glass, 3mm (Quick Response)
• Sealing Assembly: Rubber
