| Size | Inner Diameter (mm) | Outer Diameter (mm) | Width (mm) | Thickness (mm) | Height (mm) | Bolt |
|---|---|---|---|---|---|---|
| DN15 | 21 | 23.4 | 23 | 1.2 | 48 | M8-20 |
| DN20 | 27 | 29.4 | 23 | 1.2 | 55 | M8-20 |
| DN25 | 34 | 36.4 | 23 | 1.2 | 62 | M8-20 |
| DN32 | 42 | 45 | 25 | 1.45–1.6 | 65 | M8-20 |
| DN40 | 49 | 52 | 25 | 1.45–1.6 | 70 | M8-20 |
| DN50 | 60 | 63 | 25 | 1.45–1.6 | 88 | M8-20 |
| DN65 | 76 | 79 | 25 | 1.45–1.6 | 104 | M8-20 |
| DN80 | 90 | 93 | 25 | 1.45–1.6 | 118 | M8-20 |
| DN100 | 114 | 117 | 25 | 1.5–1.6 | 142 | M8-20 |
| DN125 | 140 | 143 | 25 | 1.5–1.6 | 168 | M8-20 |
| DN150 | 168 | 171 | 25 | 1.5–1.6 | 196 | M8-20 |
| DN200 | 220 | 223 | 25 | 1.5–1.6 | 248 | M8-20 |
