Temperature Ratings
Sprinkler: 68°C (155°F)
Cover Plate: 74°C (165°F)
Technical Specs
Thread Size: ½" NPT or BSPT
Max Working Pressure: 175 psi (12.1 bar)
Test Pressure: 30 psi (2.1 bar)
Installation Torque: 10–20 ft-lb (13.4–26.8 N·m)
Material
Body / Deflector / Tray / Plate Seat: Brass
Glass Bulb: JOB Q5, Heat-sensitive
Seal: Rubber
Cylinder: Carbon Steel
Fixing Screw / Connecting Rod: Brass / Plated Steel
Finish: Epoxy Resin Coated
Optional Component: Silicone air/dust seal
